Nortel Meridian 1 Option 81C PBX equipped with 300 station lines

Nortel Meridian 1 Option 81C PBX PABX Telephone System

Call for price quote.

Nortel Meridian 1 PABX phone switching system
with 300 station setup, believed expandable to 16,000
phone stations. Three (3) cabinet system with
common equipment network controller supervisor unit
and two auxiliary system units for peripherals, phones
and features of SMDR and Automated attendant and
voice mail. 1997 era. with some software.
Substantially complete believed with all or most cards
and components for system operation.

Meridian 1 Option 81C - Specifications

System Capacity
16,000 Ports

Memory
Redundant CP PII Flash not required 128 MB DRAM

Mass Storage Media
Redundant Multi Media Disk Unit with one 3.5" 1.44 MB floppy disk drive, one 1.024 GB hard disk drive, one CD-ROM

I/O Ports
255

Switching Networks
(Traffic CCS is at P.01 Grade of Service)
256 loops; 288,000 total CCS (or 224 loops; 240,000 total CCS (excluding service cicuits)

Busy-hour Call Completions
320,000 BHCC

Note: BHCC ratings are nominal; actual capacity is dependent on software release, site condiguration, and peripheral type.

Integrated Data Switching Capacity
Up to 19.2 Kbps Asynchronous; Up to 64 Kbps Synchronous

Trunking
Analog: Loop or Ground Start CO, FX, WATS, 2 or 4 wire E&M or 4-wire DX, DID, TIE, RAN, Paging, Meridian IP Gateway Digital: DTI, ISDN-PRI, ISDN-BRI, Meridian IP Gateway

Telephone Compability
Meridian Digital Telephones: Meridian M3901, M3902, M3903, M3904, M3905, M2006, M2008, M2008HF, M2616, M2216ACD; M2016S Secure; Inca Telecommuter
- i1010 Softphone
-Meridian M9617 USB Phone

Analog Telephones: M8000/M9000 Series 500/2500 type

Attendant Services Compatibility
Meridian 1 Attendant PC; Meridian 2250 Attendant Console, Central Answering Position (CAP)

CallPilot
IPE Version: 200 hours, 24 channels, 8,000 mailboxes with voice, fax, and desktop Tower and Rack: 1,000 hours, 96 channels, 20,000 mailboxes with voice, fax, and desktop

Meridian Mail Capacity
96 Ports; 800 Hours of storage

Symposium Call Center Server
Can be configured for up to 800 agents.
Busy-hour capacity: 16,500 calls per hour (configuration dependent)

Meridian Mail MAX Capacity
MAX 9 IPEE: 300 Agents

Symposium OPEN IVR
Virtually unlimited port size

Meridian Link Connectivity
IBM Callpath, HP CCM, Genesys T-Server, Novell Netware Telephony Services (TSAPI), Symposium TAPI Service Provider for Meridian 1, Tandem Call Application Manager (CAM), Dialogic CT-Connect

Meridian CCR Capacity
16,500 Calls per hour (configuration dependent)

Symposium Integrated IVR
96 ports
Host Protocols: 3270, 5250, VT-100, Ethernet and Token Ring

Input Voltage
AC: 180 to 280V, 50/60 Hz; DC: -40 to -56.6V

Operating Environment
Ambient Temperature
-Recommended 15-30 degrees Celsius (59-86 degrees Fahrenheit) -Absolute 10-45 degrees Celsius (50-113 degrees Fahrenheit) Relative Humidity% Without Condensation:
-Recommended 20%-55%
-Absolute 20%-80% temperature change less than 10 degrees Celsius (50 degrees Fahrenheit) per hour

Power Consumption & Heat Dissipation
Module:
Core/Network Module Network Module
Intelligent Peripheral Equipment (IPE) Module Meridian Mail Module Application Equipment Module (single)
Application Equipment Module (dual)
InterGroup Module (IGM) Pedestal

Power (watts)
360
270
460
240
140
190
0
50

Heat (BTU/hr) 1230
820
1160
820
480
650
0
170

Dimensions and Weight
Pedestal/Module/Top Cap:
Weight Empty: 40 lb. (18.2 kg)/50 lb. (22.7 kg)/15lb. (6.8 kg)
Weight Full: 70 lb. (31.8 kg)/130 lb. (59 kg)/15 lb. (6.8 kg)
Width: 32 in. (81.2 cm)/32 in. (81.2 cm)/32 in. (81.2 cm)
Depth: 26 in. (66 cm)/22 in. (55.9 cm)/22 in. (55.8 cm)
Height: 10 in. (25.4 cm)/17 in. (43.2 cm)/4 in. (10.1 cm)

Compare to similar listings on internet:

Compare to possible installed system cost (phones
available also) of about $20,000 versus new similar
system likely about $200,000 and of lesser quality.
Or excellent for backup or as parts for similar installed
system. PBX and Nortel service repair company or tech
should snap up this system.

Call us for questions or to buy: 972-889-8881 or 214-680-8328

NOTICE: Shipping paid by buyer.
